K2B Heavy Duty Stud End Thimble With Plate

Inch

mm

mm

mm

mm

mm

mm

K2B-01

4

75

75

50

17

5

22

K2B-02

4-1/2′

85

80

53

19

5

25

K2B-03

5

100

90

60

21

5

29

K2B-04

5-1/2′

110

95

65

23

5

33

K2B-05

6

115

120

70

25

10

34

K2B-06

7

135

140

80

30

10

38

K2B-07

8

155

160

100

33

10

44

K2B-08

9

175

185

115

38

10

49

K2B-09

10

190

195

120

41

15

52

K2B-10

11

210

215

130

46

15

60

K2B-11

12

225

240

140

52

15

65

K2B-12

14

240

250

150

56

20

68

K2B-13

17

290

310

180

70

20

82

K2B-14

19

320

360

220

81

20

119

K2B-15

22

375

405

240

92

20

127

K2B-16

24

410

450

250

105

25

145

K2B-17

26

450

480

280

130

30

155
